SOAR1050-TH6300B86
Discover hzsoar's 30~150Mm Customized Pan Tilt Thermal PTZ: The Future of AI Detection
Key Features:
- Supports visible camera for smoke and fire detection, and thermal imaging camera for high-temperature detection, with combined judgment to reduce false alarm rates and missed detection.
- Supports dual-spectrum perimeter protection, with recognition and tracking capabilities for humans, vehicles (motorized and non-motorized), and ships, including behavior analysis for intrusion, departure, loitering, lingering, and crossing boundaries.
- Supports ship identification and tracking.
- Allows on-site adjustment of visible light and thermal imaging camera axis alignment.
- Supports dynamic power consumption adjustments, including a low-power mode.
- Enables the setting of 3D warning zones and shielding zones, adaptable to any angle of the scene.
- Visible Camera,?resolution?2560×1440,?10.5~1260mm focal length,?120x optical zoom.
- Supports features such as autofocus, auto-exposure, auto white balance, backlight compensation, and 120dB wide dynamic range.
- Provides 3D noise reduction, optical defogging, electronic image stabilization, and strong light suppression functionalities.
- Thermal imager,?Resolution 1280×1024,?30~300mm focal length,?10x optical zoom. ??
- 10km laser range?finder.
- Offers continuous horizontal rotation of 360° and vertical rotation from -90° to 90°.
- Maximum horizontal speed of 150°/s and vertical speed of 100°/s.
- Precise servo motor drive for horizontal positioning with 0.003° accuracy and vertical positioning with 0.001° accuracy.
- Supports up to 256 presets.
- Enables automatic operation modes such as cruise scanning, full-scene scanning, and time period scanning.
- Optional dual-axis mechanical gyroscope for stabilization.
- Supports automatic rain wiper.
- Equipped with RJ45 network interface.
- Supports external RS422/485?control interface.
- Provides remote power restart function.
- Supports automatic defogging, deicing, and heating functions.
- Powered by DC48V, with low-power mode consuming 15W, ?consumption of 200W, and maximum power consumption of 300W.
- IP67?Standard,?6000V?Lightning?Protection,?Surge?Protection?and?Voltage?Transient
- Operating temperature range from -40°C to 70°C.
But what truly gives this product an edge over others is its integration with AI technology. This advanced technology enhances the ability of the camera to make distinctions that ordinary systems might miss. It ensures the most accurate detection possible, further reducing the number of false alarms. Plan an investment in a security solution that guarantees reliability, precision, and peace of mind. Choose the 30~150Mm Customized Pan Tilt Thermal PTZ from hzsoar. Experience a seamless blend of AI technology and top-notch detection features, all housed in a durable, heavy-duty design. Step up your security game with hzsoar now.
Camera Module | |
Image Sensor | 1/1.8” Progressive Scan CMOS |
Minimum Illumination | Color: 0.0005 Lux @(F2.1,AGC ON); B/W: 0.0001 Lux @(F2.1,AGC ON) |
Shutter | 1/25s to 1/100,000s; Supports delayed shutter |
Aperture | PIRIS |
Day/Night Switch | IR cut filter |
Lens | |
Focal Length | 10-860 mm，86X Optical Zoom |
Aperture Range | F2.1-F11.2 |
Horizontal Field of View | 38.4-0.34° (wide-tele) |
Working Distance | 100-2000mm (wide-tele) |
Image（Maximum Resolution：2560*1440） | |
Zoom Speed | Approximately 9s (optical lens, wide-tele) |
Main Stream | 50Hz: 25fps (2560*1440, 1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (2688*1520, 1920 × 1080, 1280 × 960, 1280 × 720) |
Image Settings | Saturation, Brightness, Contrast and Sharpness can be adjusted via the client-side or browser |
BLC | Support |
Exposure Mode | AE / Aperture Priority / Shutter Priority / Manual Exposure |
Focus Mode | Auto / One step / Manual/ Semi-Auto |
Area Exposure / Focus | Support |
Optical Defog | Support |
Image Stabilization | Support |
Day/Night Switch | Automatic, manual, timing, alarm trigger |
3D Noise Reduction | Support |
Thermal Imager | |
Detector Type | Vox Uncooled Infrared FPA |
Pixel Resolution | 640*512 |
Pixel Pitch | 12μm |
Response Spectra | 8～14μm |
NETD | ≤50mK |
Digital Zoom | 1.0~8.0× Continuing Zooming (step 0.1), zoom in any area |
Continuous Zooming | 20~300mm |
PTZ | |
Movement Range (Pan) | 360° |
Movement Range (Tilt) | -90° to 90° (auto flip) |
Pan Speed | configurable from 0.05°～150°/s |
Tilt Speed | configurable from 0.05°～100°/s |
Proportional Zoom | yes |
Motor drive | Harmonic gear drive |
Positioning Accuracy | Pan 0.003°, tilt 0.001° |
Closed Loop Feedback Control | Support |
Remote upgrade | Support |
Remote Reboot | Support |
Gyroscope stabilization | 2 axis (optional ) |
Presets | 256 |
Patrol Scan | 8 patrols, up to 32 presets for each patrol |
Pattern Scan | 4 pattern scans, record time over 10 minutes for each scan |
Power-off Memory | yes |
Park Action | preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan |
3D Positioning | yes |
PTZ Status Display | yes |
Preset Freezing | yes |
Scheduled Task | preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output |
Interface | |
Communication Interface | 1 RJ45 10 M/100 M Ethernet Interface |
Alarm Input | 1 alarm input |
Alarm Output | 1 alarm output |
CVBS | 1 channel for thermal imager |
Audio Output | 1 audio output, line level, impedance: 600 Ω |
RS-485 | Pelco-D |
Smart Features | |
Smart Detection | Area Intrusion Detection, |
Smart Event | Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, unattended baggage detection, object removal detection, Intrusion Detection |
fire detection | Support |
Auto tracking | Vehicle /non-vehicle/human/Animal detection and auto tracking |
Perimeter Detection | support |
Network | |
Protocols | ONVIF2.4.3 |
SDK | Support |
General | |
Power | DC 48V±10% |
Operating Conditions | Temperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95% |
Wiper | Yes. Rain-sensing auto control |
Protection | IP67 Standard, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
-
